RUCKUS 901-H350: Next-Gen Wi-Fi 6 Solutions

RUCKUS 901-H350-XX00 H350 Dual-Band Wi-Fi 6 Wall Switch – AP, IoT Gateway, and Ethernet Switch in One

Deliver the full range of in-room services over a single cable with the RUCKUS 901-H350-XX00 H350 Wi-Fi 6 Wall Switch. Built with patented RUCKUS BeamFlex+ technology, a built-in 2-port Gigabit Ethernet switch, and onboard BLE and Zigbee IoT, the H350 is a wall-mounted access point, IoT gateway, and Ethernet switch all in one compact unit — made for hotels, student dorms, apartment buildings, and multi-dwelling units where every room needs fast Wi-Fi, wired ports, and IoT support without a rats’ nest of cabling.

One Cable Per Room. Full In-Room Connectivity.

The H350’s biggest advantage is simple: a single cable pull per room delivers everything — Wi-Fi 6, two wired Ethernet ports, and IoT. No extra switches. No extra power supplies. No extra cabling runs.

This cuts install time, lowers build costs, and makes the H350 the most cost-effective way to wire up every room in a hotel, dorm, or MDU with full enterprise-grade connectivity.

Wi-Fi 6 Speed for In-Room Users

The H350 supports Wi-Fi 6 (802.11ax) with dual-band concurrent radios, giving guests and residents the fast, low-latency Wi-Fi they expect.

Dual-band concurrent (2.4GHz + 5GHz)
Peak data rates up to 1.774 Gbps (574 Mbps @ 2.4GHz + 1,200 Mbps @ 5GHz)
2×2:2 MU-MIMO and OFDMA for serving multiple devices at once
Supports up to 512 concurrent clients and 16 SSIDs per AP
1024-QAM for up to 25% faster speeds on Wi-Fi 6 devices
Backward-compatible with Wi-Fi 5 and older devices

Ideal for streaming 4K video, IP voice calls, and everyday cloud app use in guest rooms and private residences.

Built-In 2-Port Gigabit Ethernet Switch

The H350 includes a 1x GbE uplink port and 2x GbE access ports — so you can connect wired in-room devices directly from the wall plate with no extra switch needed.

Common in-room wired devices the H350 connects:

IPTV set-top boxes
IP desk phones
Networked minibars
Smart TVs and game consoles
Desktop computers and laptops

One unit. All your in-room wired and wireless needs covered.

Sleek Wall-Plate Design — Installs Over a Standard Outlet

The H350 sits in a low-profile wall-plate form factor that installs cleanly over a standard electrical junction box — the same spot you would put a wall socket.

Looks clean and discreet in any room
No ceiling mount required
No bulky hardware visible to guests
Fast to install — works over existing wall boxes

This is the access point guests never notice — and never complain about.

BeamFlex+ Adaptive Antennas – Smarter In-Room Coverage

The H350 uses RUCKUS BeamFlex+ adaptive antenna technology, picking the best antenna pattern in real time — on a packet-by-packet basis — to reach each device with the strongest possible signal.

This gives you:

Better in-room Wi-Fi coverage despite walls and furniture
Less RF noise from neighboring rooms and networks
Strong signal for every device — including older Wi-Fi 5 clients

Rather than sending signal in all directions at equal strength, the H350 aims signal at each device as needed — a real advantage in dense, multi-room buildings.

ChannelFly & Advanced RF Management

ChannelFly dynamic channel selection uses machine learning to find and move to the least busy channel at all times — keeping room-by-room networks fast and stable even in buildings packed with access points.

Combined with:

Client load balancing
Airtime fairness
SmartRoam for smooth client handoffs between APs

Your per-room network stays fast no matter how many rooms and devices are active.

Embedded IoT — BLE and Zigbee Built In

The H350 includes onboard BLE or Zigbee radio support built directly into the unit — giving you a unified Wi-Fi and IoT platform with no extra hardware.

This is the right tool for:

Smart door locks and access control
In-room sensors and environmental controls
Asset tracking and guest services automation
Smart minibar and energy management systems

One access point. One IoT gateway. Zero extra hardware.

SmartMesh Networking – Deploy with Less Cable

With RUCKUS SmartMesh, the H350 can build self-forming, self-healing mesh networks — cutting the need for extra cable runs in hard-to-wire buildings.

Strong Security Built In

The H350 keeps your in-room network safe with:

Flexible Management Options

Controller-free (Unleashed)
Cloud management
SmartZone / ZoneDirector
Standalone mode

Go from a single room to a full multi-property network without added complexity. Auto-provisioning and seamless firmware updates keep things running smoothly at any scale.

Works with Your Current Setup

The H350 runs on standard 802.3af/at PoE — no DC power adapter included. Works with existing CAT5e cabling and standard PoE switches. No new power infrastructure needed.

RUCKUS H350 Specifications

Feature	Specification
Model	901-H350-XX00
Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Bands	Dual-band (2.4GHz / 5GHz)
Streams	2×2:2 MU-MIMO
Peak Throughput	Up to 1.774 Gbps
Client Capacity	Up to 512 concurrent clients
SSIDs	Up to 16 per AP
Ethernet	1x GbE uplink + 2x GbE access ports
IoT	Onboard BLE or Zigbee (selectable)
Antenna	BeamFlex+ adaptive patterns
Mesh	SmartMesh supported
Channel Optimization	ChannelFly
Security	WPA3, VLANs, ACLs, Rogue AP detection
Form Factor	Wall-plate (fits standard electrical junction box)
Power	802.3af / 802.3at PoE (no DC adapter included)
Mounting	Wall-plate
Management	Unleashed / Cloud / SmartZone

Why Choose the RUCKUS H350?

The RUCKUS H350 Wi-Fi 6 Wall Switch is the smart choice for any property that needs to deliver Wi-Fi, wired ports, and IoT in every room — without running multiple cables or installing extra hardware per room. With a single cable pull, it replaces the AP, the in-room switch, and the IoT gateway in one sleek wall-plate unit that guests never notice. For hotels, dorms, MDUs, and multi-room offices, there is no faster, cleaner, or more cost-effective way to connect every room.
