Description
Processor

Intel® Core™ i3-12100, 4C (4P + 0E) / 8T, P-core 3.3 / 4.3GHz, 12MB
Graphics
Integrated Intel® UHD Graphics 730
Chipset
Intel® B660 Chipset
Memory
1x 4GB UDIMM DDR4-3200
Memory Slots
Two DDR4 UDIMM slots, dual-channel capable
Max Memory

Up to 64GB DDR4-3200
Storage
1TB HDD 7200rpm 3.5″
Storage Support

Up to two drives, 1x 3.5″ HDD + 1x M.2 SSD • 3.5″ HDD up to 2TB • M.2 SSD up to 1TB
Card Reader
3-in-1 Card Reader
Optical
DVD±RW
Audio Chip
High Definition (HD) Audio, Realtek® ALC222-CG codec
Speakers
2Wx1
Power Supply
180W 85%
DESIGN
Keyboard
USB Calliope Keyboard, Black, English (UK)
Mouse
USB Calliope Mouse, Black
Front Access HDD
None
Optional Bay
M.2 Bracket
Expansion Slots
  • One PCIe® 4.0 x16, full-height, half-length
  • Two PCIe® 3.0 x1, full-height, half-length
  • M.2 Bracket. For installing M.2 devices, M.2 bracket kit is needed. The kit is optional, or comes with pre-configured M.2 SSD or M.2 Wifi models
  • Two M.2 slots (one for WLAN, one for SSD)
Case Color
Chassis: Black, Bezel: Grey
System Fan
None
Stand
None
Carry Handle
None
Toolless Chassis Screw
None
Dust Filter
None
Form Factor
Tower (13.6L)
Dimensions (WxDxH)

145 x 294 x 340 mm (5.71 x 11.57 x 13.39 inches)
Weight

Around 5.5 kg (12.1 lbs)
CONNECTIVITY
Ethernet
Intel® I219-V, 1x RJ45
WLAN + Bluetooth
None
Front Ports
  • 1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging)
  • 2x USB 3.2 Gen 1
  • 2x USB 3.2 Gen 2
  • 1x headphone / microphone combo jack (3.5mm)
  • 1x microphone (3.5mm)
Optional Front Ports (configured)
1x card reader
Rear Ports
  • 4x USB 2.0
  • 1x HDMI® 1.4b
  • 1x DisplayPort™ 1.4
  • 1x VGA
  • 1x Ethernet (RJ-45)
  • 1x headphone (3.5mm)
  • 1x serial (9-pin)
Optional Rear Ports (configured)
1x Parallel
Monitor Cable
None
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0, TCG certified
Fingerprint Reader
No fingerprint reader
Physical Locks
  • Kensington® Security Slot™, 3 x 7 mm
  • Padlock Loop
Smart Cable Clip
None
Chassis E-Lock
None
Chassis Intrusion Switch
None
MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in
CERTIFICATIONS
Green Certifications
  • REACH
  • RoHS compliant
  • TCO Certified
  • WEEE
Other Certifications
TÜV Rheinland® Ultra Low Noise
SOFTWARE
Operating System
None
Bundled Software
None
ACCESSORIES
Bundled Accessories
None
